Our diamond lapping film roll is engineered for high-efficiency polishing of metal, ceramic, and composite rollers. With superior cutting speed and flexible grinding performance, it ensures precise, consistent finishes for industrial rollers used in electronics, printing, and mechanical applications. The PET-backed film offers excellent durability and cost-effectiveness, making it a preferred choice for high-volume polishing and finishing operations.
Product Features
High Cutting Speed for Increased Efficiency
Designed for aggressive material removal, the film roll achieves fast polishing results, significantly reducing overall processing time in high-demand industrial environments.
Durable Polyester (PET) Film Backing
The high-strength PET backing delivers enhanced film stability and durability during operation, allowing it to maintain performance even under continuous and high-pressure use.
Precision Finishing with Consistent Grit Distribution
Each roll features uniformly distributed diamond particles that ensure tight tolerance and repeatable polishing results across the entire surface area, from start to end.
Long Service Life with Cost-Effective Performance
The combination of high durability and competitive pricing provides excellent cost-per-use, making the film roll suitable for both small-scale operations and high-volume production.
Flexible Grinding Angle for Complex Surfaces
The film's flexibility allows it to conform to curved or irregular roller surfaces, ensuring uniform contact and smooth finishes on even the most challenging geometries.
Product Parameters
|
Product Name |
Diamond Lapping Film Roll |
|
Grit Sizes |
60µm / 45µm / 30µm / 15µm / 9µm / 6µm / 3µm / 1µm |
|
Roll Sizes |
4 in × 50 ft (101.6mm × 15m), 4 in × 150 ft (101.6mm × 45m), etc. |
|
Colors |
Blue, Green, Red, Yellow, etc. |
|
Backing Material |
PET (Polyester Film) |
|
Film Thickness |
75μm (3mil) |
Applications
3C Electronics: Used in the finishing of high-precision electronic components requiring ultra-flat, smooth surfaces.
Rubber Rollers: Perfect for pre-finishing and finishing of industrial rubber rollers in various machinery.
Mirror Rollers: Achieves high-gloss, reflective finishes essential for printing and lamination processes.
Motor Commutators: Ensures clean, even surfaces for electrical contacts and improves motor performance.
Ceramic and Tungsten Carbide Rollers: Ideal for high-hardness materials requiring fine polishing control.
Recommended Uses
Perfect for grinding and polishing ceramic rollers in the electronics industry, where flatness and smoothness are critical for product quality.
Ideal for finishing mirror rollers used in printing and coating lines, producing ultra-smooth, reflective surfaces that ensure high-performance output.
Effective for removing surface defects on tungsten carbide rollers, improving product lifespan and operational reliability.
Suitable for polishing motor commutators, enhancing electrical conductivity and reducing friction for improved motor efficiency.
Recommended for industrial maintenance of embossing and corrugated rollers, helping restore original surface conditions and prolong service intervals.
Order Now
Our diamond lapping film rolls come in various grits and sizes for precision surface finishing, with options for bulk orders, samples, and custom OEM solutions - contact us for specifications and pricing.
